DESCRIPTIONStandard Modular Design, Compact Structure
Heavy duty overhead crane adopts lightweight, modular and parametric design. Hoisting mechanism uses the new Chinese windlass crab with high integration. Traveling mechanisms of the trolley and crab are drove by three-in-one drive device and the control mechanism adopts the advanced variable frequency and speed regulation control system.
The new-type overhead crane with hookadopts the design philosophy of seriation, standarization and modularization. Using modern computer technology and introducing advanced technology, to fabricate a kind of crane that adapt to the development of the industry through.
PRODUCT FEATURESLight deadweight, small wheel pressure, effectively saving plant cost
- Light deadweight, small wheel pressure, low clearance, effectively saving plant cost
- Small limit of hook, large working area, wide coverage range
- Less transmission links, high transmission efficiency, low failure point
- High quality parts, small maintenance, long service life
- Frequency control of the whole crane, stable braking, safe and convenient to use
- The power of the whole crane is small, which effectively saves electric power resource
- Support multiple-selection: anti-sway of hook, double braking etc
Product AdvantagesAdvanced Fabricated Technology
- Sandblasting pretreatment for the steel plate, its surface quality can reach to Sa2.5.
- Using digital cutting machine to cut the web plate, ensure the smooth and precision of the camber curvilinear.
- Main welding seam adopts auto arc merged welding, Ultrasonic, X ray nondestructive inspection.
- The bridge and trolley frame adopts floor type boring machine to ensure the flatness of the machine side.
Zero Speed Hover
Ensure that the crane moves slowly and accurately as it approaches its destination.
Electric Anti-sway Function
Can automatically limit the sway of the loader in the process of handling, faster handling and more accurate positioning.
Multi-hook Coordination
Monitor and control position difference of multiple hooks to make the hooks run synchronously at the same speed.
Dead Slow
Dead slow function can ensure the stability of the control system and slow, accurate movement when the crane is moving and loading.
Multi-trolley Synchronization
Position difference of multiple cranes can be monitored and controlled to make the crane operating mechanism run synchronously at the same speed.
Speed Expansion Function
Our cranes can add sub-low speed and sub-high speed function regulation except for low speed and high speed, which is practical and efficient.
PROJECT REFERENCES
Proven Track Record: 100,000+ Cranes Speak To Our Knowledge And Reliability
LD 5t Single Girder EOT Cranes
- Applications: Manufacturing Industry
- Product: Single Girder EOT Cranes
- Advantages: Lightweight Constructio, Lightweight Constructio
